Hot Air Soldering Station JBC JTSE-2QB
Hot Air Soldering Station JBC JTSE-2QB
Precision rework – JBC JTSE-2QB
JBC JTSE-2QB is a professional hot-air station from the Premium Line for SMD rework (QFP, PLCC, QFN). 700W of power, a 150–450°C range, and 5–50 SLPM flow ensure fast, uniform heating. Up to 25 profiles combine temperature and flow, ensuring repeatability without thermal shock. A Type-K thermocouple input allows for on-board temperature measurement. USB-A/USB-B ports, RS-232, and an optional footswitch simplify integration. Heating/Profiles/Cooling modes and a 30% vacuum (228 mmHg) support disassembly. Includes a JT-T2A and 4/6/8 mm nozzles. ESD compliance and a compact size are ideal for service and R&D. The stand automatically switches the tool to standby mode, extending the heater's life.
zł9,499.99
Tax included
Product availability
Last remaining items
Delivery options
Learn more
JBC JTSE-2QB Hot Air Station – 700W, Precision and Repeatability for Professionals
Discover the JBC JTSE-2QB – a professional 700W hot air station for SMD rework (including QFP, PLCC, QFN). A range of 150–450°C, adjustable flow 5–50 SLPM, and the ability to save up to 25 profiles guarantee process control and repeatable results in service and production.
Important Note!
We recommend using original JBC nozzles and accessories (JN series, pedal, etc.).
They guarantee the best blowing quality, process stability, and longer tool life. Using substitutes may reduce performance and precision.
Key Advantages of the JBC JTSE-2QB
- ⚡ 700 W Power: Fast heating and safe desoldering of demanding circuits (QFP, PLCC, QFN).
- 🌡️ Precise Control: Temperature Range 150–450°C, flow 5–50 SLPM, modes: Heating / Profiles / Cooling.
- 🧠 Up to 25 profiles: fully customizable profiles combining temperature and flow – repeatable process without thermal shock.
- 📏 Type-K thermocouple: temperature monitoring directly on the PCB – protection of sensitive components.
- 🔌 Connectivity and automation: USB-B (PC software), USB-A (updates/profile), RS-232 (robot/FAE), pedal input – convenient control.
- 🧲 Built-in vacuum: 30% / 228 mmHg / 9 inHg – rework support.
- 🛡️ ESD compliance: safe operation in EPA zones; optional potential connection.
- 🧯 Standby mode: automatic detection of tool placement saves energy and extends heater life.
- 🌍 Multilingual menu: incl. English, German, Spanish, and French.
- 📦 Compact dimensions: the station is ideal for workstations with limited space.
Technical specifications
- Model / MPN: JTSE-2QB (Premium Line)
- Rated power: 700 W, 230 V power supply
- Temperature range: 150–450°C (300–840°F)
- Airflow: 5–50 SLPM
- Vacuum: 30% / 228 mmHg / 9 inHg
- Operating Modes: Heating / Profiles / Cooling
- Profiles: Up to 25, fully configurable
- Thermocouple: Type-K input (PCB temperature control and protection)
- Connectivity: USB-B (PC), USB-A (FW/profile), RS-232 (robot/FAE), pedal input
- ESD: EPA compliant; optional potential bonding
- Operating conditions: 10–50°C (50–120°F)
- Station dimensions (L×W×H): 232 × 148 × 160 mm
- Station weight: 4.93 kg
- Package dimensions (L×W×H): 490 × 485 × 278 mm
- Weight with packaging: 6.01 kg
Included
- Control unit JTSE (Premium Line) + tool stand with automatic standby
- Hot air tool JT-T2A
- Nozzles: Ø 4.0 mm JN2015, Ø 6.0 mm JN2012, Ø 8.0 mm JN2020
- Type K thermocouple PH218 + Kapton tape PH217
- Power Cord
- User Manual
JBC JTSE-2QB is a complete solution for professional SMD rework – speed, repeatability, and full process control.
